154120 BLDC Motor Electric Aircraft Engine for Unmanned Aircraft Large Drone Multi Rotor Drone
The 154120 is a high-performance brushless DC motor designed for a wide range of propulsion systems. It is specifically designed to work seamlessly with a propeller size of 47 and a 24S 300A ESC, ensuring smooth and reliable operation, delivering a maximum thrust of up to 80KG.
80 KG
Max. Thrust
47 N·m
Max. Torque
100% hand-winding wire with special coating layer, featuring temperature resistant, aging resistant and fireproof.
World-renowned bearing, ensuring trouble-free service over 1800 hours.
Curved magnet, it improve efficiency, dissipate heat effectively, and minimize vibration and noise.
0.2mm laminations, thinner laminations improve power density and lead to higher efficiency, smoother operation.
Application 1/2
Heavy lift drone
Application 2/2
Paraglider
Main Specifications
Specs shown here are test results based on standard model, you are most welcome to contact us to customize a product that work the best for you.
ø154mm x 120mm
54 / customized
80KG
47N·m
3642
24S 300A
47 inch
252A
90V
18KW
14S-24S
Optional
5.9KG
